Main Materials Needed for Handmade Paper Shelves
1. Classification of corrugated cardboard
1.1: Classified by flute type: A, C, B, E and their combinations, such as: AB flute, BC flute, BBC flute, etc. Now there are finer corrugated F flutes on the market for production use.
1.2: Classified according to the number of base paper layers: two-layer cardboard, three-layer cardboard, four-layer cardboard, five-layer cardboard, seven-layer cardboard, etc.; paper shelves
1.3: Classification by corrugated shape: U-shaped, V-shaped, UV-shaped; UV-shaped in general on the market now;
1.4: Corrugated performance comparison:
Flute type Flute height Flute number/30mm Shrinkage ratio Flat compressive strength Side compressive strength.
Funimprint Display Cardboard
A 4.5-5.0 34+2 1.55 4 1
C 3.5-4.0 38+2 1.47 3 2
B 2.5-3.0 50+2 1.36 2 3
E 1.1-2.0 96+2 1.26 1 4
1.5: Corrugated display:
C flute B flute A flute
1.6: Other:
Corrugated: Flute; single corrugated cardboard (also known as three-layer cardboard): single wall; double corrugated cardboard (also known as five-layer cardboard): double wall; seven-layer corrugated cardboard: triple wall;
2. The production process of corrugated cardboard
bridge connection
2.1: Working principle of single-sided machine (positive pressure single-sided machine):
2.2: Principle overview: the corrugated base paper is formed by the opposite pressing of the upper and lower corrugating rollers, and the paste is applied by the upper and lower corrugating rollers. The belt on the flyover to the double-sided machine is compounded with other single corrugated cardboard and face paper.
Paper shelf production process:
1. Design: The design of paper shelves (paper display stands) requires designers to be familiar with 3D structural work, and to consider the weight and volume of goods to calculate the bearing capacity and space area of paper shelves (paper display stands).
2. Sample production: paper shelves (paper display stands) generally use non-printed corrugated paper materials. Input the data of the design structure drawing into the computer cutting machine, the cutting machine will make a standard flat paper shelf (paper display stand) on the unprinted corrugated paper according to the indentation strength and half-knife depth required by the structure drawing, and the designer uses glue to paste and For other process processing, the next step can be done if the template is consistent with the design structure drawing.
3. Printing: According to the graphic design draft of the paper shelf (paper display stand) template, the film will be printed on the printing machine.
4. Post-process: printing color paper with glossy glue, laminating paper (printing paper + corrugated paper), oiling, and creasing.
5. Packaging: Semi-finished paper shelves (paper display stands) are assembled, reinforced, and then loaded with finished products.
Why use Funimprint cardboard POS display?
1. Weight light-Easy to transport and carry.
2. Environmentally-friendly – 75% recycled material, and 100% recyclable after use.
3. Printable – we print directly onto the cardboard surface with superior quality results.
4. Easy to work with – Easy-assembling, saving shipping cost , labor and power.
5. Knocked down packing-Can be knocked down packed to save shipping cost.
6. Customized ability friendly-Can be customized in both structure and graphics.
7. Eye catching-Suitable for goods merchandising and promotion.
